Lightspeed Live Capture is a scalable, multi-channel on-premise capture solution for ingesting live, live linear or tape-based media directly into production, post-production and broadcast workflows— and perfect for Edit@Home real-time remote production

To discuss your needs or try all of the features of Lightspeed Live Capture: contact sales or find a reseller.

LIGHTSPEED LIVE CAPTURE

C2+

LIGHTSPEED LIVE CAPTURE

C4

LIGHTSPEED LIVE CAPTURE

C5

Our base server model, the C2+ Live Capture server is a flexible and scalable video capture solution supporting four (4) SD/3G-HD SDI inputs, one (1) QuadLink 3G UHD input as well as numerous IP formats such as Transport Streams.

For exact performance capabilities refer to the latest Lightspeed Live Capture User Guide.

The Live Capture C4 server offers a high performance option in the Live Capture server family.

The Live Capture C4 server supports 8 concurrent HD captures for most available HD codecs or 2 concurrent UHD/4K up to 60p of most formats.

For exact performance capabilities refer to the latest Lightspeed Live Capture User Guide.

The Live Capture C5 server offers the highest performance option in the Live Capture server family, identical to the C4 server!

The Live Capture C5 server supports 8 concurrent HD captures for most available HD codecs or 2 concurrent UHD/4K up to 60p of most formats with 8 3G SDI ‘confidence’ monitoring outputs.

For exact performance capabilities refer to the latest Lightspeed Live Capture User Guide.

LIGHTSPEED LIVE CAPTURE

C2+

Our base server model, the C2+ Live Capture server is a flexible and scalable video capture solution supporting four (4) SD/3G-HD SDI inputs, one (1) QuadLink 3G UHD input as well as numerous IP formats such as Transport Streams.

For exact performance capabilities refer to the latest Lightspeed Live Capture User Guide.

LIGHTSPEED LIVE CAPTURE

C4

The Live Capture C4 server offers a high performance option in the Live Capture server family.

The Live Capture C4 server supports 8 concurrent HD captures for most available HD codecs or 2 concurrent UHD/4K up to 60p of most formats.

For exact performance capabilities refer to the latest Lightspeed Live Capture User Guide.

LIGHTSPEED LIVE CAPTURE

C5

The Live Capture C5 server offers the highest performance option in the Live Capture server family, identical to the C4 server!

The Live Capture C5 server supports 8 concurrent HD captures for most available HD codecs or 2 concurrent UHD/4K up to 60p of most formats with 8 3G SDI ‘confidence’ monitoring outputs.

For exact performance capabilities refer to the latest Lightspeed Live Capture User Guide.

Features

More Options

And more options to extend the system!

Beyond the myriad of base features, you add options that increase your capabilities to edit live and growing files, control playback of files and playlists — and even schedule the capture of live planned events:

  • Avid integration option - create Avid media for Media Composer or MediaCentral | Production (Interplay)
  • Live Edit sub-clipping option - multiple users can view and edit captured clips via a simple powerful web-based UI. Learn More.
  • Live Schedule option - browser based scheduling application for Live Capture event recordings. Learn More.
  • Live Play option – browser based SDI playback software option for Live Capture servers. Learn More.
Auto Capture Ingest

Enterprise-Class Automated Capture & Ingest

Scalable, automated, multichannel IP and SDI capture solution for ingesting live or tape-based media directly into production, post-production and broadcast workflows. Lightspeed Live Capture processes video in 16-bit space to preserve total source quality and it records in wide variety of mezzanine file formats to local or shared NAS/SAN storage, with delivery options to FTP, object storage (S3), Aspera, Signiant and more.

Easy To Use

Easy-to-Use Web Interface

Designed with a simple, intuitive web-based, HTML5 compatible user interface. Allows for complete control or remote management from any web portal and scales easily for large system deployment. Built-in scheduling, gang control, Recurring Segments, DAI (SCTE) and Web Services API make setting up ingestion and capture events extremely easy.

Wide Format Support

Wide Format Support & Delivery Options

Record into enterprise-class codecs and containers ready for any workflow. Support for MPEG2 TS, DNxHD/HR, AVC Intra, Apple ProRes, XDCAM, HEVC, MXF OP1a, Avid MXF OPAtom, and many more. Deliver files to open workflows via growing capture, write to onboard RAID or external network storage including NAS, SAN and object storage such as S3.

Avid Adobe Checkin

Support for Avid MediaCentral | Production (Interplay) Check-in

Lightspeed Live Capture allows you to check your captured assets (even if they’re still capturing) directly into Avid or Adobe-based NLE systems. Whether your editors are using Interplay or just Media Composer or Adobe CS, they can grab growing files captured by Lightspeed Live Capture and begin editing right away. No need to wait, no need to change your post-production workflow – your turnaround time just got faster.

Multi Channel IIP

Multi-Channel IP and SDI Capture

Capture and process 3G or 12G SDI inputs up to UHD/4K, MPEG-2 (SPTS, MPTS), RTMP or ST2110 sources all within a single, compact 1RU server. Combine multiple units together to build a capture farm that can be run and managed remotely. Includes support for LTC time code, captions, timecode burn-in, override, audio channel mapping, and metadata labels and variables.

Growing File Record

Growing File Record for Open Workflows

Record any source into growing files for instant, ongoing delivery to any production or processing workflow. Record and share edit-ready formats with Avid MediaCentral | Production (Interplay), Adobe Premiere Pro, Switch, Apple Final Cut Pro and more. Lower turnaround times for clips, highlights or promo packages in live and post-production environments. This includes both on premise or remote via WAN acceleration technologies such as Aspera and Signiant.

VTR Deck Control & Tape Logging

Automated RS422 VTR Deck Control & Tape Logging

Easily manage multiple SDI-connected VTR decks in the GUI or using hot-key based transport controls. Control decks and capture actions remotely via the Web Services API. Built-in scheduling, triggering and automation features allow for set-it and forget-it capture and ingest workflows. Error-resistant whole-tape ingest means you will capture the entire tape without interruption, even if it is damaged or missing information. Easily define and bind capture variables, populate labels for downstream actions.

16 Bit Video Processing

16-bit Video Processing

Never lose a bit. Superior, real-time video signal processing inherited directly from our industry-leading media processing platform, Vantage. Lightspeed Live Capture processes video in 16-bit space to preserve the highest quality assets and adhere to source material with complete accuracy. Future-ready for UHD, HDR, WCG, SMPTE 2020 processing requirements.

Live Capture To Vantage

Live Capture to Vantage

Create Live Capture and Tape Capture origin actions in the Vantage Workflow Designer to initiate smart, automated media processing workflows within a corresponding Vantage domain. Seamlessly and efficiently condition your media for contextualized viewing windows with correct branding, ads, captioning, ABR packaging, etc. all from a single capture event.

Software Options

Live Schedule

Live Schedule

Live Schedule is a browser based application for scheduling Live Capture event recordings.

  • Events can be added to the schedule manually, through a robust API or imported from an XML file
  • Single events can be automatically duplicate across multiple channels, making scheduling multi-channel events a breeze
  • Associated metadata appears automatically in the UI, where data can then be entered into single or multiple events
  • Editing events is easy as well — scheduled events can be quickly modified prior to the event’s start, or if already recording, the end times can be updated while the event is in progress
  • The Schedule interface allows an operator to view the status of current and past events, or look at upcoming events on a channel by channel basis - or for individual Channel Groups
  • Varying User roles are supported, allowing for view-only access

Live Edit

Live Edit is a Sub Clipping Option for Lightspeed Live Capture

  • Live Edit allows for lightning fast Sub Clipping of files being captured by Live Capture - or from previously captured sources
  • Like all Capture and Vantage workflows, metadata can be added to support any requirements
  • Live Edit is ideal for creating quick highlights, posting to Social Media, creating VOD, Multiscreen or any other deliverable required - with only the minimum delay
Live Edit
Live Play

Live Play

  • Supports a wide variety of codecs and containers
  • Playback of up to 8 simultaneous SD/HD assets
  • Playback growing TIFO or MXF OP1a files being made by Live Capture
  • Web based browser user interface
    • Manually Add, Remove, or Reorder clips
    • Trim start and end of clips in the playlist
    • Supports mixed format playlists
    • Supports format normalization for playback
    • Supports time code and ANC data playback
    • Play a single file or multiple files in a playlist
    • Import and Export playlist configuration
    • Playback from local or shared network storage
    • Full REST API for powerful automated control
